市販NR750とVFR750(4) 体積効率(3)

出典は
 Technical Review 全論文一覧 | 本田技術研究所 論文サイト (hondarandd.jp)
中、Vol.04の「ホンダNR用楕円ピストンエンジンの開発」です。


 VFR750と比較し市販NR750の体積効率が低い回転数域が広くなっていることに関し、吸気管、排気管の形状、サイズ以外の要因の2つ目は

(2)市販NR750のバルブ面積、バルブ開口面積はV型8気筒としては小さい

です。

 出典の本文中に「NRの吸気バルブの全周長がVFRに比べて45%も長い」とあります。NRの吸気バルブ径は20mmですので、VFRの吸気バルブ径は27.5mm辺りになります。

 VFR750の吸気バルブ径を27.5mmとし、バルブ面積を比較すると
NR750:50.3c㎡
VFR750:47.5c㎡
で、NR750の吸気バルブ面積はVFR750の5.8%増に留まります。

 本来、4気筒・バルブ径27.5mmエンジンを8気筒化すれば、バルブ径27.5mmを2の1/3乗で除して
バルブ径:21.83mm
バルブ面積:59.9c㎡ (VFR750の26%増、NR750の19%増)
を確保できるにも関わらず。

NRの評価     HONDA (ganriki.net)
でも書きましたが、NR750のバルブ径は当時の一般市販車レベルより小さいのです。

 さて、
出典のFig.3.2に次の図があり、本文では吸気バルブの有効開口面積で比較しています。


 縦軸が「Geometrical~」になっていますが、これは誤りで、
http://www.jsae.or.jp/~dat1/mr/motor26/mr20072616.pdf
では
、「Effective Opening Area」になっています。そもそもGeometrical~がこんな曲線になるはずはありません。

(続く)
PR

市販NR750とVFR750(3) 体積効率(2)

出典は
 Technical Review 全論文一覧 | 本田技術研究所 論文サイト (hondarandd.jp)
中、Vol.04の「ホンダNR用楕円ピストンエンジンの開発」です。


 前回お示ししたように、VFR750と比較し市販NR750の体積効率が低い回転数域が広くなっています。体積効率は特に吸気管、排気管の形状、サイズが大きく影響しますが、ここでは他の要因として2つのことを指摘します。

(1)2吸気口が近接し、かつ同時に吸気する

 V型8気筒であれば各気筒の吸気行程は90度ずつずれています。しかし、NR750はV型8気筒を2気筒ずつ連結したような形のため、その2気筒分の吸気行程が重なっています。しかも、2気筒分繋いだために2気筒に比べシリンダー幅が18%短くなり、吸気口が隣接してしまいます。
 こちらに写真があります。
Honda NR750 fixing no.2 修理 その2 : SHINYO MAG / シンヨ マグ (livedoor.jp)

 このため、2ストロークV型4気筒で同時点火にしたのと同じことが起きると考えられます。
JFRMCブログ 同時点火化による出力低下(2) (tou3.com)
JFRMCブログ 同時点火化による出力低下 (tou3.com)




市販NR750とVFR750(2) 体積効率

 Technical Review 全論文一覧 | 本田技術研究所 論文サイト (hondarandd.jp)
中、Vol.04の「ホンダNR用楕円ピストンエンジンの開発」のFig.3.3で、市販NR750とVFR750の体積効率が比較されています。

 体積効率については、
体積効率 [JSME Mechanical Engineering Dictionary]

 このFig.3.3の数値を読み取り、再現してみました。横軸はrpm/100、縦軸が体積効率(%)で、赤線がNR750、黒線がVFR750です。10000rpm以下でのNR750の体積効率の低さが目立ちますね。


 例によって、横軸を各エンジンの最高出力発生回転数比で整理しました。幅広い回転数比域でVFR750>NR750です。


 これにトルクを重ねます。左縦軸が体積効率(%)、右縦軸がトルク(kgf・m)。

 回転数比0.65前後で、2機種の体積効率とトルクの関係が変化することが分ります。




市販NR750とVFR750

 本田技術研究所のウェブサイトでテクニカルレビューが公開されています。
Technical Review 全論文一覧 | 本田技術研究所 論文サイト (hondarandd.jp)
Vol.04に「ホンダNR用楕円ピストンエンジンの開発」というペーパーがあり、市販NR750とVFR750のデータが比較されています。

 その中のFig.3.1の出力曲線から数値を読み取り、出力・トルク曲線を作成してみました。

赤線がNR750、黒線がVFR750、横軸がrpm/100、左縦軸が出力PS、右縦軸がトルク・kgf・mです。どの線が出力なのか、トルクなのかの説明は不要ですよね。

 なお、NR750の公表出力は130PSですが、Fig.3.1では127PS程度にしか見えません。VFR750(本来はVFR750F)の最高出力は仕向地によって異なるようですが、102~104PS程度と思われます、これもFig.3.1では98PSです。これは、個体差、測定条件(気温等、測定箇所(変速機出力軸なのか、クランクシャフト換算なのか)の差なのでしょう。
 本来はVF750ではなく、VFR750R(RC30)が比較対象でもよかったと思います。

 例によって、横軸の回転数を各エンジンの最高出力発生回転数に対する比率で整理しトルク曲線を作成してみました。

 赤線がNR750、黒線がVFR750です。

 図示した回転数比の範囲ではVF750の方がトルク変動が少ないように思えます。




バリー・シーンに渡ったスズキRS67Ⅱ

スズキRS67Ⅱの記事

RS67 SUZUKI (その1)
RS67 SUZUKI (その2)

のその2で、「TEAM SUZUKI」(by Ray Battersby, Osprey 1982)の記述を参考に、シーンがRS67Ⅱエンジンを所有していることについて書き、サミー・ミラー・ミュージアムに展示されているRS67Ⅱのエンジンがシーン所有であったものと推定していました。

 このことについて、TEAM SUZUKIの著者自身から情報提供がありました。上の「その2」のはその内容を加筆済ですが、こちらにもその内容を紹介します。

The story of Barry Sheene's RS67-2 By Ray Battersby, 2021

In 1978, I visited Sheene's latest home, Charlwood Manor at Charlwood near Gatwick airport. Barry showed me around his home and workshops and led me inside one of his private workshops. I noticed a very dilapidated RS67 engine standing inside a wooden crate beneath a workbench. It was the first time that I had seen this motor other than in photographs. Sheene dragged it out and I photographed it from all sides*.

I asked Sheene how he had obtained the engine. He told me that at the end of 1977, he had visited the Suzuki race-shop at Hamamatsu to test the 1978 race machines. During this visit he stayed at the Grand Hotel in Hamamatsu as do all of Suzuki's guests and visitors. He was having a drink in the Grand Hotel Skyline Bar one evening when he met Suzuki's European Sales Manager. During their chat, Sheene asked him what had happened to Suzuki's famous old racing machines.

The next day, Barry was taken to a small store-room at the Suzuki factory, somewhere near the lakes used by Suzuki to test their outboard engines. Inside that small store-room were many old experimental racing machines (such as RF750) and amongst these old machines, Sheene found a small wooden shipping crate. He lifted its lid and found the RS67 125 V4 engine inside. Sheene pestered his Suzuki contacts to let him have the engine and eventually they agreed. After all, Sheene was Suzuki's first 500cc World Champion.

The engine was shipped in its original shipping crate to Heron Suzuki GB's race-shop at Beddington Lane, Croydon amongst the 1978 racing machinery. It was not fitted with carburettors, magneto or expansion chambers. Eventually, Sheene and his father Franco Sheene, removed the engine and took it to their own workshops at Charlwood Manor. Soon afterwards, I visited Charlwood Manor on other business and saw the engine in its crate beneath Barry Sheene's work-bench.

It is possible that Sheene's original idea was to build this engine into a modern racing chassis but if that was his idea, he never found the time to do it. It is believed that Sammy Miller may have visited Charlwood, possibly to buy another Sheene racing machine for his museum, and saw the RS-67-2 engine there. A price was agreed and the engine went to Sammy Miller's museum workshop at Christchurch in Hampshire, England.

To complete the engine, Sammy Miller must have bought the carburettors and magneto elsewhere and had new expansion chambers made in the UK. Miller apparently ordered a replica RS67 racing chassis to be made in the UK by a company that used original photographs as a guide for its design, dimensions and shape. Some people believe the replica chassis itself is made of steel tubing, not aluminium alloy as used by Suzuki in 1967.

It is not known whether the power unit is in running order or whether this machine has ever been ridden.

 日本から流出したことは残念ですが、結果的にスクラップになるエンジンが一つ減ったと思えば、これでよかったのかもしれません。
